🔦 ROADVISION BR70AR LED SLIMLINE TWIN COMBINATION LAMP – STOP, TAIL & INDICATOR – 10–30V DC SURFACE MOUNT

Part Number: BR70AR

Please Note: Listing is for ONE light only

Roadvision’s BR70 Series LED signal lamps are built tough for Aussie conditions — delivering modern styling, high visibility, and long-term reliability.

The BR70AR is a twin combination lamp featuring amber and red LED sections for Stop, Tail, and Indicator functions. Its ultra-slim 28 mm strip design makes it perfect for applications where space is limited — trailers, caravans, utes, and light trucks.

Constructed with a sealed polycarbonate lens and a high-impact ABS housing, the BR70AR is dust-proof, water-proof, and maintenance-free. Thanks to Roadvision’s solid-state LED technology, these lamps deliver brilliant brightness while drawing only a fraction of the current of standard incandescent systems — all with a 100,000-hour LED lifespan.

With ROADVISION, it’s Fit & Forget!

✅ FEATURES

• Twin-colour Amber/Red LED lamp for Stop, Tail, and Indicator
• Ultra-slim (28 mm) LED strip design – compact and stylish
• Low current draw & multi-volt 10–30 V DC input
• Brighter than conventional incandescent systems
• 100,000-hour LED lifespan with solid-state reliability
• Sealed polycarbonate lens & high-impact ABS housing
• Water and dust-proof
• Supplied pre-wired with 300 mm LEDLink connector
• Simple surface-mount installation
• ADR/ECE approved for all functions

📏 SPECIFICATIONS

• Part Number: BR70AR
• Functions: Stop / Tail / Indicator
• Voltage Input: 10–30 V DC
• Number of LEDs: 15 × High-Output LEDs
• Current Draw: 0.10 A / 0.50 A @ 13.8 V
• Dimensions (mm): 252 L × 28 H × 23.5 D
• Lens Construction: Polycarbonate
• Housing Construction: High-impact ABS
• Mounting Hole Centres: 234 mm
• Cable Length: 300 mm tinned cable
• ADR Approval: ECE E4-7R-028536

💡 ALSO AVAILABLE IN THE BR70 RANGE (all sold separately in our store)

BR70R – Stop / Tail Lamp – 10–30 V DC – 15 LEDs – 0.10 / 0.50 A @ 13.8 V – 252×28×23.5 mm

BR70A – Rear Indicator Lamp – 10–30 V DC – 15 LEDs – 0.13 A @ 13.8 V – 252×28×23.5 mm

BR70W – Reverse Lamp – 10–30 V DC – 15 LEDs – 0.13 A @ 13.8 V – 252×28×23.5 mm

BR70AS – Sequential Indicator Lamp – 10–30 V DC – 15 LEDs – 0.12 A @ 13.8 V – 252×28×23.5 mm

Roadvision BR70 Series – Built Tough, Shines Bright!
