2 Amp Direct-Mount Battery Charger and Maintainer

Introducing the GENIUS2D, one of our most powerful, highest-performing, energy-efficient, and compact chargers yet. The GENIUS2D is a 2-amp direct-mount battery charger and battery maintainer engineered to be securely mounted nearby the battery. Its designed for all types of 12-volt lead-acid batteries, including flooded, gel, AGM and other maintenance-free batteries.

• All-new next-generation battery charger – now smaller, lighter, and with improved features to increase battery life.
• Designed for 12-volt lead-acid batteries, including most flooded, gel, AGM, and maintenance-free, as well as automotive, marine, RV, and deep-cycle batteries.
• The perfect battery maintainer for daily battery maintenance or long-term storage of cars, boats, trucks, RVs, and equipment, plus suitable for charging ATVs, wave runners, lawn mowers, and more.
• Engineered to be securely mounted nearby the battery with its rugged snap-fit mounting bracket and effortlessly installs into most materials with truss-head self-tapping screws.
• Integrated thermal sensor to maximize battery life and automatically compensates charging for both cold and hot environments.
• Enjoy countless hours of safe charging without any risk of overcharging your batteries, plus additional safety like spark-proof connections, and reverse polarity protection.
• Includes a 2-amp direct-mount battery charger and battery maintainer with a 24-inch Type-A A/C cable and 24-inch D/C cable with eyelets, plus a mounting bracket, self-tapping truss-head screws, and user guide, plus a 3-year hassle-free warranty.

SPECIFICATIONS

Multi-Voltage. Multi-Chemistry. Multi-Battery Type.

A multi-functional design that allows you to charge in more ways. Effortlessly charge multiple battery voltages (6-Volt and 12-volt lead-acid and lithium-ion batteries) chemistries (Flooded, gel, maintenance-free and AGM batteries) and types (Starter, deep-cycle, marine, powersport and more).

Our Most Powerful, Efficient, and Compact Charger Yet.

Compact, yet powerful battery charger. A mix of electrical engineering and industrial design pack a powerful battery charger into a tiny footprint. The GENIUS2 uses high-frequency switch-mode technology to efficiently convert A/C power into safe D/C power for battery charging. And its onboard microcomputer precisely controls the charging to minimize power loss to create an incredibly compact form factor.

Improved Start Voltage Sensor.All-New Force Mode.

The all-new start-voltage sensor allows the GENIUS to detect and charge dead batteries as low as 1-volt.For extremely dead batteries lower than 1-volt, manually turn on force mode to detect and charge batteries all the way down to zero volts.

More Precise Charging in Any Climate.

The new integrated thermal sensor automatically monitors and adjusts the charging cycle based on fluctuations of ambient temperature, limiting the chance of under-charging or over-charging, providing a more accurate and fully charged battery.Avoids under-charging in cold weather down to -4 F and avoids over-charging in hot weather up to 104 F.

Auto Detection. Auto Repair. Improved Performance.

The GENIUS2 automatically detects sulfation/acid stratification.If any is found, the GENIUS2 will automatically repair and reverse the damage done to the battery, extending the usable life and increasing the performance.

Year-Round Charging. Zero Overcharge. Auto Memory.

Finally a charger from start to finish that’s completely automatic. No special modes, no technical knowledge required. Genius will safely charge any battery. Detect damaged batteries and intuitively repair them. And actively monitor for long-term battery maintenance and extend battery life. This system allows for continuous operation without user intervention, and zero risk of overcharging your battery.

Improved Clamping Range.Improved Clamping Force.

Genius clamps are built with needle-nose profiles for smaller terminal applications and detachable integrated eyelets for permanent mounting the accessory to battery.Designed to fit battery terminals of any shape and size. Engineered for improved clamping range, clamping force, and higher conductivity.

Technical Specifications

What’s In The Box?

• GENIUS2 Battery Charger w/ Interchangeable Connector
• Clamps w/ Integrated Eyelets (M6)
• Mounting Bracket w/ Strap
• (2) Self-Tapping Screws
• User Guide & Warranty Information

Operating Requirements

Voltage: 120-240V
AC Frequency: 50-60Hz
Operating Temperature: -4 degree to 104 degree F (-20 degree to 40 degree C)
Storage Temperature: -22 degree to 140 degree F (-30 degree to 60 degree C)
Relative Humidit: 0 to 95% Non-Condensing
IP Rating: IP65

Charging

Current: 2 Amps DC
Voltages: 6V / 12V
Chemistry: Lead-Acid and Lithium
Types: Wet, Gel, MF, CA, EFB, AGM, Lithium
Capacity Range: Up to 40 Amp-Hours
Maintenance: All Battery Sizes

Power

Consumption: 30 Watts (Max)
Efficiency: 87% (120VAC / 230VAC)

Safety

Short-Circuit: Yes
Open-Circuit: Yes
Overheating: Yes
Overcharge: Yes
Spark-Proof: Yes
Reverse Polarity: Yes

Size

Height: 3.7 Inches (94mm)
Width: 2.4 Inches (61mm)
Depth: 1.7 Inches (43mm)
Weight: 1.1 Pounds (0.5kg)

Cord Management

DC Cable + Clamp Length: 77 Inches (195cm)
DC Cable Size: 18 AWG
DC Fuse Size: 4 Amp Mini Blade Fuse
AC Cable Length: 71.7 Inches (182cm)
AC Cable Size: 18 AWG

Oil, gas, grease, water, chemical, UV, abrasion-resistant
