Hayman Reese Compact Brake Controller
Remote Mount Brake Controller

The Hayman Reese Compact joins the already reliable range of Hayman Reese Brake Controls and like the name suggests is compact enough to be installed with space in mind.

The controls are mounted in the dash of the vehicle, with the main control unit mounted out of sight. There are very few tools needed to carry out the installation of the Hayman Reese Compact with a drill, crimp tool, wire cutter and circuit tester all you need to complete your job.

Components of the Brake Control
A. Compact size
B. Quick Connect Plug
C. Power Output Control/ Manual Override Button
D. Sync Control
E. LED indicator

Features and Benefits

• Compact size
• Electric trailer brake control for 1-3 Axles
• Plug & Play feature allows for quick and easy connection with the Hayman Reese Smartclick™ brake control harness
• Unique “Sync” adjustment for towing diff erent trailers
• Flexible and neat mounting options
• Green LED Indicator monitors a secure connection with your trailer
• 3 Year Limited Warranty
• Remote mount ensures no issues with hitching the brake control unit or damaging it, whilst moving in your vehicle
• Remote mount is less likely to interfere with any airbag deployment zones e.g. knee or lower leg
• 65(l) x 65(w) x 35(h)

Plus HOT Wiring Kit

This Kit Includes everything required to carry out a standard installation:

suits Tekonsha P3, IQ, Voyager, Redarc Towpro Elite & Classic, GSL RBC-12-NG, HAYMAN REESE 05550 +HAYMAN REESE 05650

• 8 metres of 4 core ‘Brake Controller’ wire
• 5 metres of 13mm split loom conduit to protect your wiring
• 30 amp uto reset circuit breaker for power supply
• 30 amp auto reset circuit breaker for brake controller
• 2x circuit breaker protective covers
• 10x cable ties
• Crimp terminals – 4x small ring, 3x large ring, 5x large joiner, 1x medium joiner
